Kiaro
Uncompromised, maximum riding enjoyment: Our new KIARO road bike combines top performance with stable smoothness - and style. The carbon frame matches stiffness, for maximum power transfer, with targeted flex for increased comfort. And all those smart little details are the cherry on top!
Curious what the following configuration packages are all about?
Then take a look at our magazine article!
Faster, further, KIARO
The KIARO is more than just a racing bike - it stands for speed, endurance and comfort at the highest level. The modern carbon frame absorbs bumps without sacrificing agility and guarantees the stability you need for fast sprints and dynamic handling. Kilometer after kilometer, it keeps you racing powerfully and efficiently.
Every detail counts on long tours! That’s why an integrated multitool and compact storage bag for the downtube, in which a spare tube can be stored, are included as part of your delivery. The cover also offers a nifty attachment for a CO₂ cartridge. Thanks to the tire clearance of up to 38 mm and the optional Curana mudguards, the KIARO offers even more flexibility and is equipped for any weather and any terrain. Comfort, functionality and performance in perfect harmony - even off the tarmac!
GeometrY
The geometry table will help you find the perfect frame size. If you are unsure, our experts will be happy to help you with a free online consultation.
| 46/XXS | 49/XS | 52/S | 55/M | 58/L | 61/XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat tube length | 420 | 450 | 480 | 500 | 520 | 550 |
| B | Top tube horizontal | 511 | 525 | 539 | 552 | 568 | 583 |
| C | Head tube angle | 69° | 70° | 71,5° | 72° | 72° | 72° |
| D | Seat tube angle | 74° | 74° | 74° | 74° | 74° | 74° |
| E | Head tube length | 125 | 143 | 160 | 181 | 200 | 221 |
| F | Chainstay length | 410 | 410 | 410 | 410 | 412 | 412 |
| G | Wheelbase | 991 | 997 | 998 | 1006 | 1025 | 1041 |
| H | Bottom bracket drop | 74 | 74 | 74 | 74 | 74 | 74 |
| I | Fork length | 387 | 387 | 387 | 387 | 387 | 387 |
| K | Fork offset | 50 | 50 | 50 | 50 | 50 | 50 |
| M | Standover | 724 | 750 | 775 | 794 | 812 | 838 |
| R | Reach | 358 | 366 | 374 | 380 | 380 | 391 |
| S | Stack | 534 | 555 | 577 | 599 | 617 | 637 |
| STR * | Stack to Reach | 1,42 | 1,43 | 1,42 | 1,44 | 1,42 | 1,44 |
| R+ | Reach+ | 428 | 438 | 457 | 464 | 485 | 494 |
| S+ | Stack+ | 610 | 630 | 651 | 673 | 692 | 712 |
| STR+ | Stack to Reach+ | 1,42 | 1,43 | 1,42 | 1,44 | 1,42 | 1,44 |
| U | -12° | -12° | -12° | -12° | -12° | -12° | |
| V | 90 | 90 | 100 | 100 | 110 | 110 | |
All lengths in mm
* STR: Higher number indicates more upright sitting posture
Facts & Figures
| MAX. weight (bike + rider + GEar) | 130 kg |
|---|---|
| FORK TRAVEL / LENGTH / OFFSET | 0 / 387 / 50 mm |
| AXLE STANDARD FRAME | 142 x 12 mm |
| THRU-AXLE | 172 x M12 x 1.0 mm |
| Fork installation dimensions | 100 x 12 mm |
| MAX. tire dimension | ETRTO: 38-622 / Inch: 28 x 1.50 |
| MAX. brake rotor size | 180 mm |
| brake mount | FM160 |
| seat tube diameter | 27,2 mm |
| headset standard | IS52 ICR/IS47 |
| Headset | ACROS AIA552 |
| MAX. chainring size | 53/39T |
| DERAILLEUR HANGER | UDH |
| water bottle mounts | 2 |
| CHILD TRAILER READINESS | No |
| COMPATIBILITY BIKE RACK | No |
| The illustration above is an example. We reserve the right, provided that the type, suitability and purpose of the bicycle are not impaired, to replace individual parts with components of equal or higher value so that the bicycle is delivered differently. |
Bike classification: ASTM category 1
Learn more (PDF)
 |
|
