Pavo

The PAVO marks an unprecedented fusion of lightweight construction and aerodynamics. Its state-of-the-art autoclave production in Europe allows carbon frames of the highest quality: extremely light and safe at the same time. All frame tubes have been aerodynamically optimised through flow simulations. The PAVO combines the best of both worlds and offers an enormously wide range of uses: uphill it’s light, on the flat it’s accelerated by low air resistance.

from

€ 6,899.00

from

CHF 6,899.00

Lightweight

Endurance

Race

Aero

Print

Prices in EUR

Prices in CHF

print technologies and options

print geometry table

Ask an expert

Perfection in function and manufacturing

Frame material

Carbon

Frame weight

800 g (M)

Max. system weight (bike + load)

125 kg

UCI compliant

Yes

Bike trainer

approved

Total bike weight

from 6,83 kg

Pavo

Ask an expert

configure now

Find a Dealer

Evolution to perfection

The fourth generation of the PAVO combines the genes of its predecessors with our experience from developing the aero rocket "PRIDE II" (currently the fastest UCI-compliant road racing bike in the world).

Aerodynamics meets comfort

The beautifully integrated clamping of the seat post with Comfort Concept offers a high level of seating comfort with maximum aerodynamic performance.

Eminence Front

Orderly protection for the cables and an aerodynamically optimized front surface: This is provided by the cable routing of the Smart Headset, in which all cables run inside the frame from the headset.

Slim Silhouettes

The small frontal area, which has been optimized for minimal air resistance using flow models, pushes the Pavo IV to maximum performance while maintaining a low weight.

Strength Conditioned

The extraordinary rigidity of the bottom bracket and chainstay ensure optimal power transmission. So that your power transfers to the asphalt.

Beautiful Efficiency

The perfect integration of fork and head tube scores points not only with its elegant design, but also with its particular stability and rigidity, thanks to our I-Cone technology.

Superlight Strength

Additional carbon layers reinforce critical areas (like the rear dropout here) and ensure maximum stability in a super light frame.

Broadside Attack

The Pavo takes it with tires up to 34 mm wide. The bottom bracket has been designed to provide maximum width support, ensuring the greatest possible drive rigidity.

Curious what the following configuration packages are all about?

Then take a look at our magazine article!

Versatile aero road bike for climbing the peaks

In its fourth model generation, our PAVO achieves an unprecedented fusion of lightweight and aerodynamics. It thus covers an extremely wide range of uses: uphill it spurs with its low frame weight, on the flat it is uncompromisingly fast thanks to the low air resistance of the aerodynamically optimized frame shape. It thus combines the genes of all PAVO models with our developers experience with the Pride II, currently the fastest UCI-compliant road bike on the market.

This previously unattained combination of light weight and aerodynamics was made possible by tube cross-sections optimized by computer simulation and state-of-the-art autoclave production in Portugal.

Geometry

The geometry table will help you find the perfect frame size. If you are unsure, our experts will be happy to help you with a free online consultation.

		46/XXS	49/XS	52/S	55/M	58/L	61/XL
A	Seat tube length	442	469	501	520	540	560
B	Top tube length	509	530	550	557	583	588
C	Head tube angle	71°	71,5°	73°	73°	73°	73°
D	Seat tube angle	75°	75°	75°	75°	75°	75°
E	Head tube length	111	130	146	166	186	205
F	Chainstay length	410	410	410	410	410	410
G	Wheelbase	976	988	991	1002	1008	1013
H	Bottom bracket drop	75	75	75	75	75	75
I	Fork length	379	379	379	379	379	379
K	Fork offset (rake)	47	47	47	47	47	47
M	Stand over height	725	755	780	800	820	840
R	Reach	370	380	390	395	400	405
S	Stack	520	540	560	580	600	620
STR *	Stack to Reach	1,41	1,42	1,44	1,47	1,50	1,53
R+	Reach+
S+	Stack+
STR+	Stack to Reach+
U	Steam angle	-12°	-12°	-12°	-12°	-12°	-12°
V	Stem length	90	90	100	100	110	110

All lengths in mm
* STR: Higher number indicates more upright sitting posture

Ask an expert

features

State-of-the-art production in Europe: The Pavo Frame

The PAVO sets standards in frame production. Its UCI-certified carbon frame is manufactured in Europe, it is aerodynamically optimized and a flyweight. This rare combination is possible because we make no compromises in development and manufacturing:

The aerodynamically optimized frame shape was developed with the help of flow simulations.
The highest-quality carbon fibres ensure stiffness and low weight.
The full monocoque frame is manufactured as one single component (instead of being assembled from several parts). This saves weight and increases stability.
The autoclave curing process under pressure results in an extremely compact fibre composite and therefore maximum safety.
A combination of manual and state-of-the-art robotic finishing processes ensures the frame's ultimate perfection.

Find out more about our PAVO special frame manufacturing process in this magazine article.

Facts & Figures

Technical details

Bike Weight	from 6,55 kg
max. weight (bike + rider + gear)	125 kg
FORK TRAVEL / LENGTH / OFFSET	0 / 380 / 47 mm
REAR AXLE / THRU-AXLE LENGTH / THREAD PITCH	142 x 12 mm
front axle	100 x 12 mm
max. tire dimension	ETRTO: 34 - 622 / 28 x 1.35 Inches
MAX. brake rotor size	180 mm
break mount	FM160
HEADSET STANDARD	IS52 ICR/IS47
BOTTOM BRACKET STANDARD	PF BB86
MAX. CHAINRING SIZE	53 / 39T
UDH DERAILLEUR HANGER	No
water bottle mounts	2
MAX. water bottle size	2 x 750 ml
BIKE TRAINER READINESS	k.A
UCI conformance	Yes
CHILD TRAILER READINESS	No

technologies

Smart Headset more information
Full Internal Cable Routing more information
Asymmetric Chainstays more information
Comfort Concept more information
Hollow Carbon Dropouts more information
I-Cone more information
Hot Melt Carbon more information
Vibrex more information

Intended use

Bike classification: ASTM category 1
Learn more (PDF)

Bicycles and e-bikes in this category are designed for riding on asphalt, paved roads and paths. The tires are in constant contact with the ground at average speed, with the occasional steps and drops.
Jumps & drops: ≤ 15 cm
Skills: no special riding technique required
Bike type: Road Bike, City Bike

Test Reports

SIMPLON PAVO: tradition meets innovation

The first SIMPLON PAVO came onto the market 17 years ago. Now RennRad has tested the fourth generation of our classic road bike. According to the testers, we have achieved our goal of creating “a fusion of lightweight construction and aerodynamics”!
