Kagu :ePinion Mid
With the KAGU :ePinion Mid, modern technology meets sophisticated functionality. With its powerful support and integrated, efficient 12-speed gearbox, the Pinion drive ensures a harmonious riding experience - even with automatic shifting if required. The robust frame, high payload and comfortable balloon tyres make it a versatile companion for everyday use, longer tours or the commute to work.
Modern e-bike with an innovative drive system
The KAGU :ePinion with its brand-new Pinion E-Drive System sets new standards in performance, range and low maintenance. The drive system combines an electronic gear shifting with 12 gears and a strong motor with 85 Nm of power in one unit. To match the revolutionary drive system, we have developed a carbon frame for the KAGU :ePinion that provides the optimum balance of light weight, stiffness and fatigue strength. With its extremely high system weight of a maximum of 160 kg, the KAGU is an absolute workhorse for trekking, travelling and transporting heavy loads and luggage.
Range? More than enough! The flexible battery system of the KAGU :ePinion delivers battery power up to 1,495 Wh (high version) resp. 960 Wh (mid version) for limitless riding pleasure. Welcome to the future of e-trekking!
Facts & Figures
| Max. Weight (Bike + Rider + Gear) | 160 kg |
|---|---|
| Fork Travel | 0 / 465 / 50 mm |
| Axle Standard Frame | 148 x 12 mm |
| THRU-AXLE | 172 mm x M12 x 1.0 |
| Front Axle | 110 x 15 mm |
| Max. Tire Dimension | ETRTO: 60 - 584 Inch: 27.5 x 2.35 |
| Max. Brake Rotor Size | 203 mm |
| Brake Mount | PM7 |
| Seat Post Diameter | 31,6 mm |
| Headset Standard | ZS56 / ZS56 |
| Headset | ACROS AZA642 |
| DERAILLEUR HANGER | SIMPLON |
| Water Bottle Mounts | 1 |
| Motor | Pinion MGU E1.12 |
| Max. Support Level | 400 % |
| Max. Torque | 85 Nm |
| Max. Power | 600 Watt |
| Battery Capacity | 720 / 800 / 1060* Wh (*only frame size L, XL) |
| RANGE EXTENDER | - |
| Charge on Bike | yes |
| Removable Battery | yes |
| Child Trailer Readiness | yes |
| Kickstand Compatible | KSA40 |
| The illustration above is an example. We reserve the right, provided that the type, suitability and purpose of the bicycle are not impaired, to replace individual parts with components of equal or higher value so that the bicycle is delivered differently. |
Bike classification: ASTM category 2
Learn more (PDF)
 |
|
GeometrY
The geometry table will help you find the perfect frame size. If you are unsure, our experts will be happy to help you with a free online consultation.
| 41/XS | 46/S | 51/M | 56/L | ||
|---|---|---|---|---|---|
| A | Seat tube length | 410 | 460 | 510 | 560 |
| B | Top tube horizontal | 575 | 585 | 595 | 605 |
| C | Head tube angle | 69° | 69° | 69° | 69° |
| D | Seat tube angle | 73° | 73° | 73° | 73° |
| E | Head tube length | 180 | 190 | 200 | 210 |
| F | Chainstay length | 485 | 485 | 485 | 485 |
| G | Wheelbase | 1132 | 1142 | 1153 | 1164 |
| H | Bottom bracket drop | 72,5 | 72,5 | 72,5 | 72,5 |
| I | Fork length | 465 | 465 | 465 | 465 |
| K | Fork offset | 50 | 50 | 50 | 50 |
| M | standover | 557 | 558 | 560 | 569 |
| R | Reach | 374 | 381 | 389 | 396 |
| S | Stack | 657 | 666 | 675 | 685 |
| STR * | 1,75 | 1,75 | 1,74 | 1,73 | |
All lengths in mm
* STR: Higher number indicates more upright sitting posture
Trailer which are mounted on the rear wheel are allowed for this model.
